Plastic Board Machine
Your Professional Plastic Board Machine Supplier
Our goal is to become your true partner in the field of auxiliary machine China. Qingdao Zhongsu Machinery Manufacturing Co., Ltd. is committed to the design, development and manufacturing of plastic machinery, enabling its extrusion equipment technology and manufacturing techniques to rank among the leading and dominant positions in the industry. We have a skilled engineering team dedicated to refining every stage, from product development and process improvement to production oversight, ensuring every product delivered meets rigorous quality and performance standards. The price is competitive and the product is quality-assured, which is a good choice for your long-term cooperation.
Why Choose Us
Our Certifications
The company has obtained ISO9001 quality management system certification and passed the EU electrical safety and quality standard CE certification.
Production Market
Our products are well received in the market and are exported all over the world, including the Americas, Africa, the Middle East, Northern Europe, and Southeast Asia.
Our Production Capacity
Our newly built and operational medium-speed machinery plant covers a large area and has an annual production capacity of over 100 sets of various plastic machinery.
Cost-efficiency
These machines allow high-volume production at significantly lower costs compared to traditional manufacturing methods. This cost-effectiveness makes them a preferred choice for businesses aiming to maximize profitability by producing large quantities with minimal resource wastage.
Production flexibility
Plastic sheet making machines can easily switch between different material types and thicknesses, offering versatility that enables manufacturers to cater to diverse industry needs.
Enhanced product quality
These machines are designed to produce sheets with consistent thickness and smooth surfaces, which ensures high-quality end products that meet industry standards.
Energy efficiency
Modern plastic sheet making machines incorporate energy-saving technologies that help reduce overall energy consumption, making them an environment-friendly choice.
Customization capabilities
Manufacturers can easily tailor the properties of the sheets, such as adding UV resistance or color customization, to meet specific client requirements.
Specification of Plastic Board Machine
|
Extruder model |
SJ-120/33 |
SJ-150/33 |
SJ-120/33 SJ-65/33 |
SJ-150/36 SJ-65/33 |
|
Screw L/D ratio (L/D) |
33:1 |
33:1 |
33:1 |
33:1 |
|
|
|
33:1 |
33:1 |
|
|
Product width(mm) |
915-1220 |
915-1220 |
915-1220 |
915-1220 |
|
Product thickness(mm) |
14-16 |
14-16 |
14-16 |
14-16 |
|
Main motor power (kw) |
110 |
160 |
37-132 |
37-160 |
|
Max.extrusion capacity(kg/h) |
300 |
500 |
400 |
600-700 |
Unlike standard extrusion machines, the formwork extrusion machine integrates a unique internal rib-forming system, strengthening the formwork's load-bearing capacity (up to 50kN/m²). A dual-cooling system-water-cooled calibration sleeve plus air-blow cooling-prevents warping, critical for formworks requiring strict flatness. The servo haul-off unit with anti-slip rollers maintains stable traction, paired with a flying saw for precise length cutting (±3mm) to match construction site needs.
Equipped with a PLC touchscreen, it enables real-time adjustment of extrusion speed, mold temperature, and cutting length. Compared to Polypropylene hollow building board extrusion equipment for general panels, it emphasizes structural integrity and reusability (up to 50 times). With output rates 150–500 kg/h, it supports recycled PP (30–50%) and meets construction standards.
Plastic injection molding machine: A plastic injection molding machine injects melted plastic into a mold to make solid plastic parts.
Plastic extrusion machine: A plastic extrusion machine extrudes plastic in a continuous profile. The main machine is usually called the host, and its accompanying equipment are called the plastic auxiliary equipment. Plastic extruders can make plastic film/wrapping, packing tape, corrugated sheets, plastic lumber, pipes, tubes, insulated wire, monofilament and nets.
Plastic blow molding machine: A plastic blow molding machine inflates a preform or parison inside of a mold to form hollow parts.
Thermoforming: Thermoforming is a manufacturing process where a plastic sheet is heated to a pliable forming temperature, and stamped to a specific shape in a 2-part mold. Or a vacuum can be used to pull the plastic sheet onto the mold in a simplified process known as vacuum forming. The excess material is trimmed off and recycled.
Rotational molding: Rotational molding involves a heated hollow mold that is filled with a charge or shot weight of material. It is then slowly rotated (usually around two perpendicular axes), causing the softened material to disperse and stick to the walls of the mold forming a hollow part.
Application of Plastic Board Machine
Plastic molding machines are generally used in sectors such as automotive, electronics, white goods, packaging, and medical supplies. Among the produced products are car parts, electrical switches, plastic bottles, containers, medical devices, and many other plastic products.
The machines used in the molding process can handle different materials such as thermoplastics and thermoset plastics, thus providing flexible production.
Packing and Shipping of Plastic Board Machine
|
Packing |
Tray+cushioning packaging |
|
Shipping |
Shipped by road, sea, rail |
