Plastic Sheet Machine
Your Professional Plastic Sheet Machine Supplier
Our goal is to become your true partner in the field of auxiliary machine China. Qingdao Zhongsu Machinery Manufacturing Co., Ltd. is committed to the design, development and manufacturing of plastic machinery, enabling its extrusion equipment technology and manufacturing techniques to rank among the leading and dominant positions in the industry. We have a skilled engineering team dedicated to refining every stage, from product development and process improvement to production oversight, ensuring every product delivered meets rigorous quality and performance standards. The price is competitive and the product is quality-assured, which is a good choice for your long-term cooperation.
Why Choose Us
Our Certifications
The company has obtained ISO9001 quality management system certification and passed the EU electrical safety and quality standard CE certification.
Production Market
Our products are well received in the market and are exported all over the world, including the Americas, Africa, the Middle East, Northern Europe, and Southeast Asia.
Our Production Capacity
Our newly built and operational medium-speed machinery plant covers a large area and has an annual production capacity of over 100 sets of various plastic machinery.
Advantages of Plastic Sheet Machine
Efficiency and speed
They offer fast production speeds and can reduce downtime between runs due to faster adoption of new processes and quick setup.
Flexibility for post-processing
Sheets can be manipulated and remolded while still hot after leaving the extruder, allowing for further product customization.
Versatility
They can process a wide variety of plastic materials, including PVC, PP, and PE, and can create different types of sheets by adjusting settings.
Quality and consistency
The machines produce sheets with consistent thickness and a uniform cross-section. Advanced features like precise temperature control and automated systems ensure high accuracy and quality.
Specification of Plastic Sheet Machine
|
Production Capacity |
500 kg/hr |
|
Power Consumption |
50KW-400KW |
|
Operation Mode |
Automatic |
|
Phase |
Three |
|
Frequency |
50 Hz |
|
Power Source |
Electric |
|
Diameter |
Calender rolls Diameter are from 250mm up to 1000mm |
|
Weight |
1 ton to 40 ton |
|
Size |
10 meter to 60 meter |
|
Thickness |
0.5 to 30 mm thick sheet can be produced. |
|
Design |
Latest and tested. |
|
Driven Type |
Electrically |
|
Material |
Alloy |
Equipped with a 75mm twin-screw extruder (L/D 36), the sheet making machine enables targeted melting regulation (160-190℃ for PP, 150-180℃ for PE)-ensuring consistent material flow without degradation, a critical factor for reliable sheet quality. The forming unit adopts a precision T-die with adjustable lip (±0.08mm tolerance) to guarantee uniform thickness, while a multi-zone water cooling system rapidly sets the sheet shape, preventing distortion during handling.
For high-output needs, the PP PE sheet making machine offers an optional double-layer co-extrusion module-allowing simultaneous production of sheets with different PP/PE ratios (e.g., PE inner layer for toughness + PP outer layer for scratch resistance). Its traction unit uses silicone-coated rollers (speed 2-10m/min adjustable) with pressure control, avoiding surface marks on soft PE sheets, and an automatic edge-trimming system removes surplus material for clean sheet edges.
Types of Plastic Sheet Machine
Extrusion machines
These machines shape molten plastic through a die to form sheets. They are ideal for large-scale production and are valued for their ability to produce uniform sheets efficiently.
Calendaring machines
In this method, the plastic passes between heated rollers to form sheets. It is particularly suitable for producing thin sheets with a smooth finish.
Thermoforming machines
Used primarily for creating specific shapes from plastic sheets, thermoforming machines are ideal for applications requiring detailed and intricate designs.
Application of Plastic Sheet Machine
Packaging: In the packaging sector, extruded sheets are commonly processed into blister packs, clamshells, and protective inserts. Their lightweight nature, high impact resistance, and ease of thermoforming help protect products during transportation, extend shelf life, and support efficient manufacturing.
Construction: The construction industry relies on extruded plastic sheets for applications such as wall panels, insulation layers, interior partitions, and protective barriers.
Automotive: In automotive manufacturing, extruded sheets support the production of lightweight interior and exterior components, including trims, panels, dashboard elements, and protective linings.
Electronics: Thanks to their insulating properties, extruded plastic sheets are used for device housings, internal insulation layers, mounting structures, and protective covers.
Retail and advertising: Clear or printable sheet materials such as PETG, PVC, and acrylic are commonly used in point-of-sale displays, signboards, and promotional fixtures. Their transparency, smooth surfaces, and compatibility with various printing technologies enable high-quality visual presentation.
Healthcare: The healthcare sector uses chemically resistant and sterilizable plastics for trays, instrument containers, organizers, and other components requiring hygiene and durability.
Packing and Shipping of Plastic Sheet Machine
|
Packing |
Tray+cushioning packaging |
|
Shipping |
Shipped by road, sea, rail |
FAQ
